Hydraulic Lifter Panel Making Machines , Automatic Sandwich Panel
Production Line
mgo board panel making machines production line in China building
material machinery
Equipment components
This automatic mgo board production line in China is made up of two
parts, Board making machine line and Board four-sides cutting
machine Line
1. Board Making machine Line
No. | Name | Function | Size (mm) | Power(KW) | Quantity(set) |
1 | Slurry mixer | Mixing cement mortar of up and own materials | 2300×820×820 | 3 | 2 |
2 | Main mixer | Mixing middle materials | 2800×1500×1300 | 18.5 | 2 |
3 | Crusher | Crush and collection material after cutting | 1960×880×1070 | 11 | 1 |
4 | Duplex units feed in mould board | Automatic feed-in mould board on the main formed units, no need by
manual, can reduce labor, improve work speed. | 4800×3100×2800 | 1.5 | 1 |
5 | Main formed units | It includes all of device of automatic feed-in cement mortar, fiber
cloth, spreading, one-time forming and etc. | 29000×1800×1500 | 11.5 | 1 |
6 | oil brusher | It can adhibit the PVC paper on the mould board by automatic. (Or
brush the oil on the mould board) | 2700×1600×800 | 1.1 | 1 |
7 | Automatic tracking cutting device | It can cut the product on production line when it’s wet, and it
will not hurt the product and mould board, reduce the labor, low
labor intensity . | 4500×2000×1450 | 2.45 | 1 |
8 | Hydraulic lifter of receiving board system | It can load the formed board on the form rack, reduce labor, reduce
hurting the board when by manual, and improve automatic. | 2700×3800×1700 | 9.6 | 1 |
9 | PLC Control system | Control the production line automatic. | 750×500×1800 | | 1 |
We are professional manufacturer of different kinds of lightweight
wall panel machines----precast hollow core wall panel machine, eps
concrete sandwich wall panel machine, ceramsite block machine,
fence wall panels made of construction waste etc. Our advantage is
that we not only make the machines, but also make the panels, so we
have rich experience.The most important part of our advantage is
not only about the machine, but also about the formulation. How to
make the best-quality panels at the lowest price according to the
materials which the customers have in their countries is our main
purpose. We can make the best formulation for our customers because
we have rich experience in this field. The materials of making this
kind of panels can be cement, fly ash, leca, perlite, eps, gypsum,
Mgo, Mgcl2/Mgso4, wood saw powder, crushed plant straws, etc.
1) Product quality: product quality is priority to the
international standard GB/T9775-1999 (equal to European Standard).
2) The gypsum board which produced by the gypsum board production
line is heat-resistant, fire-resistant, insulated, light,
nonpoisonous, little pollution, adjusting the humidity of the room.
3) We can offer a basket of services of design, producing,
installation, commissioning and training, as well as turnkey
project for customers.
No. | Test Item | National standard | Wall panel testing |
1 | Compressive strength | ≥3.5MPa | ≥3.7MPa |
2 | Drying shrinkage | ≤0.6mm/m² | 0.37mm/ m² |
3 | Hanging force | ≥1000N 24hours No 0.55mm crack in 24hours | ≥1000N 24hours No 0.55mm crack in 24hours |
4 | shock resistance | without crack shocked by 30kgs sandbag five times | without crack shocked by 30kgs sandbag five times |
5 | The bending failure load | ≥1.5 times of the self weight of the wall panel | ≥2.5 times of the self weight of the wall panel |
6 | radioactivity | Inner radiation index Ira≤1.0 Outer radiation index IY≤1.3 | Inner radiation index Ira≤1.0 Outer radiation index IY≤1.3 |
7 | density | ≤90kgs/m² | ≤43kgs/m² |
8 | Air insulation of sound | ≥35dB | ≥43dB |
9 | Fire resistance limit | ≥1 h | ≥ 1h |
