    Fiber Cement Board Production Line , Full Automatic Cold Roll Forming Equipment

    Ask Lasest Price
    Brand Name : chuangxin
    Model Number : XD-1
    Certification : CE
    Price : 30000USD
    Payment Terms : L/C, T/T
    Supply Ability : 10 set per month
    Delivery Time : 30 days
    • Product Details
    • Company Profile

    Fiber Cement Board Production Line , Full Automatic Cold Roll Forming Equipment

    Fiber Cement Board Production Line , Full Automatic Cold Roll Forming Equipment


    Full Automatic Non-asbestos fiber cement board Production Line With Larger Capacity

    Basic technical data
    1 Product name: Non-asbestos fiber cement board
    2 Standard: In conformity with National Building Material Industry Standard JC/T 412.1-2006.
    3 Raw material: Cement, reinforced fiber, additives
    4 Product specification: ( L*W*T) 2440× 1220× 6-2mm
    5 Capacity: 3000 PCS /day ( calculate by 2440× 1220× 6mm board, 24 working hours continous production )
    6 production organization arrangement: 1) 3shifts per day, 8hours per shift, 300working days per year 2)total wokers need for this line is 52 staff, including 2 management staff, 2 techincal staff and 48 workers...
    TypeD Density
    (g/cm3)

    Water absorption
    %
    Water content
    %
    waterprooftness
    %
    expansion ratio

    noninflam

    mability

    f
    Low density0.8≤ D≤ 1.1
    ---
    ≤ 12
    __
    ≤ 0.25
    Autoclaved and curing products
    ≤ 0.5
    meet GB8624 Grade A
    Medium density1.1≤ D≤ 1.4≤ 40
    __
    24H checking allow damp mark on the back of the board, but no water drop
    High density1.4≤ D≤ 1.7≤ 28

    __
    Compressive Strength~20 MPa (3, 000 PSI)
    Impact Resistance> 6 kJ/m2
    Tensile Strength> 5.5 MPa
    Density (Specific Mass)~1000 Kg/m3 (+/-< 2%)
    Moisture Absorption~26% maximum saturation (slow absorption rate)
    Moisture Content~6%
    Water Vapour Diffusion~28 / 35
    Specific Heat~930 J/kgK
    Thermal Conductivity~0.44 W / mK
    Modulus of elasticity~6045 N/mm2
    Flexibility
    UNI E 12372
    ~20.1 N/mm2 maximum
    12mm x 1220 x 2440 = 10 N/mm2
    Surface Alkalinity~10 Ph
    Thermal Expansion Hot/Cold0, 01 mm/mC (from temp +20C to -20C)
    Expansion in Waterless than < 0.02% from ambient to saturation
    Freeze / Thaw - UNI EN 520100 cycles without notable effects
    Frost Resistanceno water drops form on surface
    Combustibility / Fire Ratingsnon-combustible / 12mm exceeds 1 hr fire rating
    Dimensional tolerancethick 0.2mm / width 2mm / length 3mm / Sq. 3mm
    Toxicity Pollutants Heavy Metals - UNI EN 12457-2Below measurable levels of test instruments
    Asbestos AnalysisAbsent - not measurable
    Formaldehyde AnalysisAbsent - not measurable
    Sound Attenuation (9mm)tested design ASTM E90 = STC 48, 50, 55, & 60
    ColorSlate Grey and Chalk White
    Surface texturesmooth one side; uniform machine textured back
    Basic Compounds(MgO)+(natural silicates)+(glass fibre)+(wood fibre)

    Fiber Cement Board Production Line , Full Automatic Cold Roll Forming EquipmentFiber Cement Board Production Line , Full Automatic Cold Roll Forming Equipment
